Miller Edge Inc.

MGS20 Sensing Edge


The Miller Gate Square Sensing Edge, or MGS20, is installed on the leading or trailing edge of the gate. It provides a 3-sided activation when touched on the front or sides of the edge, providing a safe means of stopping and/or reversing a gate’s motion should it come into contact with an obstruction.


Designed to wrap around 2” square gateposts, MGS20 edges are custom manufactured to required length and outlet location.


Note:

• Tested with most listed commercial gate operator manufacturers

• Complies with the UL 325-2016 Standard

• May be used as the required monitored device or as an ancillary device


Before designing or motorizing any gate, be sure to read and understand the ASTM-F2200 standard for gate construction. Additionally, since 2009, the International Building Code (IBC-2009) has required compliance with the current UL 325 safety standard.


Miller Edge offers a convenient guide to help you comply with the ANSI/UL 325 standard for gate entrapment protection devices. To request a printed copy of this guide, please email [email protected]
